Input Voltage 1000V 6KW 8KW Single Phase DC/AC Inverters for PV System SUN-8K-SG01LP1-EU
Product Details:
| Place of Origin: | Anhui, China |
| Brand Name: | Deye |
| Model Number: | SUN-5K-12K-SG01LP1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pieces |
|---|---|
| Price: | $1,080.00/pieces 2-49 pieces |
|
Detail Information |
|||
| Input Voltage: | 1000V | Output Voltage: | 220 Vac/ 230 Vac/ 240 Vac |
|---|---|---|---|
| Output Current: | 40A | Output Type: | Single, Triple, Three Phase |
| Size: | 840W*345H*375D | Type: | DC/AC Inverters |
| Inverter Efficiency: | 98.4 % | Certificate: | CEI 0-21, VDE-AR-N-4105, IEC61727, IEC62116 |
| Warranty: | 5 YEARS, 5 Years | Weight: | 35.0 Kg (26.5 Lb) |
| Product Name: | Deye Inverter | Inverter Type: | Three Phase Hybrid Inverter |
| Battery Voltage: | 160 ~ 700 Vdc | Battery Type: | Gel And Lithium Battery |
| Keyword: | Deye Hybrid Inverter | MPPT Voltage Range: | 150V-850V |
| Maximum PV Array Power: | 6500 Wp | Lead Time: | 10 Working Days After Receive The Payment |
| Application: | Hybrid Solar Power System | ||
Product Description
Product Description
Model | SUN-5K-SG01HP3-EU-AM2 | |||||||||||||||
Battery Input Data | ||||||||||||||||
Battery Type | Lithium-ion | |||||||||||||||
Battery Voltage Range (V) | 160~700V | |||||||||||||||
Max. Charging Current (A) | 37 | |||||||||||||||
Max. Discharging Current (A) | 37 | |||||||||||||||
Number of battery input | 1 | |||||||||||||||
Charging Strategy for Li-Ion Battery | Self-adaption to BMS | |||||||||||||||
PV String Input Data | ||||||||||||||||
Max. DC Input Power (W) | 6500W | |||||||||||||||
Max. DC Input Voltage (V) | 1000 | |||||||||||||||
Start-up Voltage (V) | 180V | |||||||||||||||
MPPT Range (V) | 150V-850V | |||||||||||||||
Full Load DC Voltage Range (V) | 195-850 | |||||||||||||||
Rated DC Input Voltage (V) | 600 | |||||||||||||||
PV Input Current (A) | 20A+20A | |||||||||||||||
Max. PV ISC (A) | 30A+30A | |||||||||||||||
Number of MPPT / Strings per MPPT | 2/1 | |||||||||||||||
AC Output Data | ||||||||||||||||
Rated AC Output and UPS Power (W) | 5000W | |||||||||||||||
Max. AC Output Power (W) | 5500W | |||||||||||||||
Peak Power (off grid) | 1.5 times of rated power, 10 S | |||||||||||||||
AC Output Rated Current (A) | 7.6/7.3 | |||||||||||||||
Max. AC Current (A) | 13 | |||||||||||||||
Max. Continuous AC Passthrough (A) | 40A | |||||||||||||||
Output Frequency and Voltage | 50/60Hz;3L/N/PE 220/380Vac，230/400Vac | |||||||||||||||
Grid Type | Three Phase | |||||||||||||||
DC injection current (mA) | <0.5%1n | |||||||||||||||
Efficiency | ||||||||||||||||
Max. Efficiency | 97.60% | |||||||||||||||
Euro Efficiency | 97.00% | |||||||||||||||
MPPT Efficiency | 99.90% | |||||||||||||||
Protection | ||||||||||||||||
PV Input Lightning Protection | Integrated | |||||||||||||||
Anti-islanding Protection | Integrated | |||||||||||||||
PV String Input Reverse Polarity Protection | Integrated | |||||||||||||||
Insulation Resistor Detection | Integrated | |||||||||||||||
Residual Current Monitoring Unit | Integrated | |||||||||||||||
Output Over Current Protection | Integrated | |||||||||||||||
Output Shorted Protection | Integrated | |||||||||||||||
Surge protection | Integrated | |||||||||||||||
Output Over Voltage Protection | DC Type II / AC Type Ⅲ | |||||||||||||||
Certifications and Standards | ||||||||||||||||
Grid Regulation | VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150 | |||||||||||||||
Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||||||||||||||
General Data | ||||||||||||||||
Operating Temperature Range (℃) | -40~60℃, >45℃ Derating | |||||||||||||||
Cooling | Smart cooling | |||||||||||||||
Noise (dB) | <55 dB | |||||||||||||||
Communication with BMS | RS485; CAN | |||||||||||||||
Weight (kg) | 35 | |||||||||||||||
Size (mm) | 840W*345H*375D | |||||||||||||||
Protection Degree | IP65 | |||||||||||||||
Installation Style | Wall-mounted | |||||||||||||||
Warranty | 5 years | |||||||||||||||
Specification
Packing & Delivery
FAQ
A: What are your main products?
D: How does your factory conduct quality control?
Quality first. We have a professional QC team to control the quality strictly. Only when the quality meets the requirements, will it be packaged out of the factory.
E: What are your strengths in solar systems?
Fully automatic production line using international advanced production equipment such as Japan and Germany. The price and quality are very competitive, and we have cooperated with many well-known brands. And we can supply large solar energy series products.
F: How can I do if I need more help with the order?
You can chat with our sales online or send inquiry email, we will respond to you immediately. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.
If you want to know more information, you can send inquiry to our team, we will cover more details.
We have many series of solar products, mainly producing solar systems, solar panels, solar inverters, powerwall, solar lithium ion batteries,solar application solutions and solar mounting systems, and all related solar accessories.
B: Are you a factory or trading company?
We are a factory with more than nine years of experience in producing solar energy series products. You are welcome to visit our factory.
C: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, comprehensive tech support, and after-sales services.
B: Are you a factory or trading company?
We are a factory with more than nine years of experience in producing solar energy series products. You are welcome to visit our factory.
C: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, comprehensive tech support, and after-sales services.
D: How does your factory conduct quality control?
Quality first. We have a professional QC team to control the quality strictly. Only when the quality meets the requirements, will it be packaged out of the factory.
E: What are your strengths in solar systems?
Fully automatic production line using international advanced production equipment such as Japan and Germany. The price and quality are very competitive, and we have cooperated with many well-known brands. And we can supply large solar energy series products.
F: How can I do if I need more help with the order?
You can chat with our sales online or send inquiry email, we will respond to you immediately. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.
G: Is sample available and free?
Sample will charge cost, but the cost will be refund after bulk order.
Sample will charge cost, but the cost will be refund after bulk order.
If you want to know more information, you can send inquiry to our team, we will cover more details.
